Disc
maitre cylindre de palonnier Ø11
258 € TTC
corps alu 7075 T6 anodisé noir mat, piston inox joint epdm pour liquide DOT4 diamètre de piston : 11mm, course : 20mm entre axe de fixation : réglable de 138 à 144mm, plus long sur demande fixation : 2 Ø6mm, Entrée et sortie M10*1.25 poids : 120g avec rotule
Product compatible with kit :
Diamond Wheel - Roues freinées 6"L=4.00 S - 6 pistonsDescription
Features
Downloads
maitre cylindre de palonnier Ø11
| Features | Detail |
| Materials | Alu 7075 T6 anodisé noir mat et inox 304 |
| Diamètre de piston | Ø11 mm |
| Course | 20 mm |
| Entre axe de fixation | réglable de 138 à 144 mm, plus long sur demande |
| Fixation | 2 Ø6mm |
| Weight | 120g avec rotule |
| Entrée et Sortie | M10*1.25 |
Rim
Rocket
À partir 3 540€ TTC
The EVOSKIL ULM rim is a fusion of advanced composite material technologies, aeronautical manufacturing processes and innovative design. It offers exceptional performance, strength and durability for a safer, more efficient flying experience. Benefit from cutting-edge technology combining safety, performance and durability for an incomparable flying experience.
The kit includes 2 braked wheels equipped with :
2 4.00x6'' carbon rims
2 rockets
2 systèmes de freinage comprenant 2 étriers de 3 pistons
2 conduits rigides de liaison entre les 2 étriers avec vis banjo titane
Our design process
01
Compression molding
Carbone Hex MC is subjected to a temperature in excess of 100°C and a pressure of 30 tons in a specially designed press, shaping the material with custom molds.
02
Extraction and separation
Once the molding process is complete, the rim is carefully extracted and separated from the mold, using organic and natural products.
03
Visual and dimensional inspection
The rim undergoes a rigorous assessment, where we visually check its finish and precisely measure its dimensions to guarantee conformity.
04
Deburring
Any burrs of resin that may remain after molding are gently removed, ensuring a perfect finish for each piece.
05
CNC machining
The rim is machined using a digital milling machine to drill the holes needed to insert the assembly screws and tire inflation valve.
06
Mounting bearings and pins
We use special tools to fix the stainless steel pins to the rim, ensuring optimum positioning and facilitating subsequent fitting of the brake disc.
